Product Description

Used for 2-axis servo positioning control, material cutting machine (high-speed servo control), crane operations, material clipper controlled by the servo.

• MPU points: 16
• Max. I/O points: 512
• Program capacity: 64K Steps
• Communication port: Built-in RS-232 and RS-485, compatible with MODBUS ASCII / RTU communication protocol.
• Data register: 10,000 words (latched)
• 500KHz high-speed pulse output:
• Built-in 2 groups of A/B phase differential signal ouput
• X-axis pulse output: (FP0+, FP0-), (RP0+, RP0-)
• Y-axis pulse output: (FP1+, FP1-), (RP1+, RP1-)
• Supports Manual Pulse Generator (MPG) and multi-point external signal inputs
