Boring Machine Control System

Get a Price/Quote

Boring Machine Control System Specification

Starting Type
Soft Start

Torque
18 Nm

Pressure
Standard Atmospheric

Rated Frequency
50 Hz

Efficacy
High Efficiency

Noise Level
<68 dB

Power Rating
3.5 kW

Horse Power
4.7 HP

Sealed Type
IP65 Sealed Enclosure

Features
Energy Saving, Digital Display, Programmable Logic, Emergency Stop

Motor Type
AC Synchronous Motor

Cooling Method
Air Cooled

Current Type
AC

Voltage
380 V AC

Poles Number
4

Rated Voltage
380 V

Product Type
Boring Machine Control System

Output Power
3.5 kW

Protect Feature
Overload, Short Circuit, Overheat

Phase
Three Phase

Power
3.5 kW

Color
Gray

Dimension (L*W*H)
600 x 420 x 220 mm

Weight
18 kg

Shaft Diameter
28 mm

Mounting Type
Panel Mount

IP Rating
IP65

Communication Interface
RS485, Modbus

Control Panel Material
Powder Coated Steel

Response Time
100 ms

Operation Mode
Automatic/Manual

Display Type
Digital LCD

Installation Location
Indoor Industrial Environment

Alarm System
Visual & Audio Indication

About Boring Machine Control System

Boring Machine Control System

Control PANEL for Horizontal Boring Machine Double Sided
Spindle motors --3 hp each
Lubrication , Hydraulic motors with Rapid Feed type Valves
Controller with Panel ,Operator Panel
Total Turnkey Project Solutions for Boring applications

Precision and Efficiency Combined

This control system delivers both high efficiency and precise control for industrial boring machines. Thanks to its responsive digital LCD and soft start feature, operators benefit from stable performance and minimal wear on components. The systems energy-saving capabilities help reduce operational costs while its programmable logic and remote communication support modern, connected workflows.

Rugged and Reliable for Demanding Environments

With a powder-coated steel panel and IP65-sealed enclosure, the system is built to withstand harsh indoor industrial conditions. Superior overload, short circuit, and overheat protection ensure uninterrupted operation. The air-cooled design and panel mounting make integration and maintenance straightforward, supporting continuous heavy-duty use while maintaining low noise levels.

FAQs of Boring Machine Control System:

Q: How does the Boring Machine Control System ensure operational safety?

A: The system is built with multiple protection features including overload, short circuit, and overheat safeguards. It also includes an emergency stop function and alerts operators with visual and audio alarms to ensure prompt response to abnormal conditions.

Q: What is the installation process and where should the control system be mounted?

A: Designed for indoor industrial environments, this control system is panel-mounted for secure installation. Its compact dimensions (600 x 420 x 220 mm) and IP65-sealed enclosure make it ideal for placing within factory control rooms or machine panels.

Q: When is it appropriate to use automatic or manual operation modes?

A: Automatic mode is recommended for routine operations requiring consistent results, while manual mode is suitable for troubleshooting, adjustments, or scenarios where operator intervention is necessary for customized control.

Q: What communication options are available for system integration?

A: The control system features RS485 and Modbus interfaces, enabling seamless integration with industrial automation networks and remote PLCs for efficient data communication and centralized control.

Q: How does the digital LCD display enhance usage and monitoring?

A: The digital LCD display provides clear, real-time feedback on key operating parameters, system alerts, and programming options, making it easy for operators to monitor performance and respond swiftly to any issues.

Q: What are the benefits of the energy-saving and high-efficiency design?

A: The system is engineered for high operational efficiency, utilizing a 3.5 kW AC synchronous motor and soft start technology to minimize energy consumption and reduce startup stress on components, which extends equipment lifespan and lowers utility costs.
