103H Stepper Driver and motors

Get a Price/Quote

Product Details:

Rated Operation Voltage 24V DC
Control System Electronic control
Panel Type None
Thickness Appropriate for industrial use; exact data unavailable
Connectivity Type Wired
Way Single phase control
Protection Level Basic protection from dust and moisture
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

103H Stepper Driver and motors Product Specifications

Maximum Output Current Up to 4.2A
Surface Color Black
Material Metal
Components Stepper driver and stepper motors
Current Rating Up to 4.2A per phase
Cover Material Metal
Rated Current 4.2A
IP Rating IP20
Cabinet Material Black coated metal
Cooling System Passive cooling
Features Precision movement high torque low noise
Operating Voltage 24V DC
Protection Class Class 1
Base Material Metal
Standard Industry standard
Display Type None
Way Single phase control
Protection Level Basic protection from dust and moisture
Application Stepper motor driving applications
Warranty 1 year
Panel Type None
Dimension (L*W*H) Compact; dimensions unavailable
Control System Electronic control
Rated Operation Voltage 24V DC
Product Type Stepper Driver and Motor set
Connectivity Type Wired
Rated Voltage 24V DC
Surface Finish Matte finish
Thickness Appropriate for industrial use; exact data unavailable

Product Description

103H Stepper Driver and motors

Stepper Drives for motors from 10 Kgcm to 220 Kgcm ( i.e 1 Nm to 22 Nm ).

Features :

1) High Performance , Cost Effective

2) Supply Voltage Upto +80V DC / 110V AC

3) Output Current : : Upto 7.8A

4) Pulse input Frequency Upto 300 Khz

5) TTL Compatible , Optically Isolated input

6) MicroStepping Type 1/256 steps resolution

7) Automatic Idle Current reduction

8) Suitable for 2 Phase / 4 Phase Stepper motors

9) Short Circuit , OverVoltage , OverCurrent , OverTemperature Protection

FAQs of 103H Stepper Driver and motors:

Q: What is the maximum current rating for the 103H Stepper Driver and motors?

A: The current rating is up to 4.2A per phase.

Q: What is the operating voltage for the 103H Stepper Driver and motors?

A: The operating voltage is 24V DC.

Q: What type of control system does the 103H Stepper Driver and motors have?

A: The control system is electronic control.

Q: What is the warranty period for the 103H Stepper Driver and motors?

A: The warranty is for 1 year.

Q: What is the protection class and level for the 103H Stepper Driver and motors?

A: The protection class is Class 1 with basic protection from dust and moisture.
