MESSUNG XMP8-10 EDIO 0/8D

Get a Price/Quote

MESSUNG XMP8-10 EDIO 0/8D Specification

Control Type
Digital

Automation Grade
Automatic

Weight
Approx. 180 grams

Application
I/O Expansion for PLC, Industrial Automation

Features
Short circuit and overload protection, Expandable IO module

Phase
Single Phase

Frequency
50/60 Hz

IP Rating
IP20

Cable Length
Dependent on installation

Load Capacity
8 Digital Inputs

Mounting Type
DIN Rail

Connectivity Type
DIN Rail Mountable

Material
Industrial Grade Plastic/Metal

Power
24 V DC

Temperature
0°C to 55°C

Voltage
24V DC

LED Indication
Yes, for each channel

Input Channels
8

Dimensions
120 x 80 x 50 mm

Response Time
<10 ms

Output Channels
8

Terminal Type
Screw Type

Isolation
Opto-isolated channels

Compatibility
Compatible with XMP8 series PLC CPUs

Fuse Protection
Yes, per output channel

Model Number
XMP8-10 EDIO 0/8D

Ambient Humidity
10% to 95% RH, non-condensing

Input Type
Digital (Sink/Source)

Output Type
Transistor (Source)

About MESSUNG XMP8-10 EDIO 0/8D

MESSUNG EXPANSION Modules ( XMP8 MICRO-Series )

Number of Inputs/Outputs : 0/8

DC Input : 24V DC +/-20%

Relay Output : 24-240V AC

Outputs Type : Transistor

Compact Design

MMI Connectivity

Doxmini Software - Powerful Programming and Documentation based Software

PG308 - Compact Portable Handheld Programming Terminal

Expansion Modules - Discrete and Analog

Reliable and Flexible Integration

Designed for compatibility with XMP8 series PLC CPUs, this expandable I/O module ensures smooth communication and flexible integration into diverse automation systems. Its DIN rail mountability enables quick installation, while the screw-type terminals support secure wiring for robust industrial applications.

Performance-Oriented Features

Equipped with opto-isolated inputs and transistor outputs, the unit offers good electrical isolation and safety. Each channel has individual LED indicators for streamlined troubleshooting and status checks. Response times under 10 ms facilitate precise digital control in demanding environments.

Durability for Industrial Demands

Built with industrial-grade materials, the XMP8-10 EDIO 0/8D can tolerate harsh conditions with ambient humidity from 10% to 95% non-condensing and temperatures from 0C to 55C. Fuse protection on every output channel and short-circuit safeguards ensure lasting operation and help maintain plant uptime.

FAQs of MESSUNG XMP8-10 EDIO 0/8D:

Q: How do I install the MESSUNG XMP8-10 EDIO 0/8D expansion module?

A: The module is DIN rail mountable, allowing for simple and secure installation in control cabinets. Ensure proper orientation, connect wiring using the screw terminals, and confirm tight connections to supporting PLC CPUs, particularly from the XMP8 series.

Q: What type of input and output channels does this module offer?

A: The XMP8-10 EDIO 0/8D provides 8 digital input channels (sink/source) and 8 transistor output (source) channels, each with individual LED indication for monitoring signals and operation.

Q: When should I use this I/O expansion module in automation projects?

A: Employ this module when you need to expand the digital I/O capacity of your PLC system, especially for applications demanding rapid response, reliable status indication, and robust protection in industrial environments.

Q: Where is the XMP8-10 EDIO 0/8D typically used?

A: This module is ideal for industrial automation processes, such as manufacturing, assembly lines, and control systems, where expansion of digital inputs and outputs is required and space-saving DIN rail mounting is beneficial.

Q: What protection features does the module include?

A: Each output channel on the XMP8-10 EDIO 0/8D is equipped with individual fuse protection, providing both short-circuit and overload safeguards to protect the system and maintain operational reliability.

Q: How does opto-isolation benefit the operation?

A: Opto-isolated channels electrically isolate the control and field sides, reducing the risk of voltage spikes or electrical noise affecting the PLC CPU or other sensitive components, enhancing safety and signal integrity.

Q: What are the benefits of the LED indication and fast response time?

A: Individual LED indicators allow for quick assessment of channel status, aiding in diagnostics and maintenance. The modules <10 ms response time ensures precise digital control, which is critical for time-sensitive industrial processes.
