MHMD082S1V Panasonic Motor

Get a Price/Quote

MHMD082S1V Panasonic Motor Specification

Phase
Single / Three Phase

Features
High precision, Compact design, Energy efficient

Mounting Type
Flange Mount

Load Capacity
0.82 Nm (Rated Torque)

Connectivity Type
Wired

Control Type
Servo Control

Automation Grade
Automatic

Processor Type
Built-in Digital Signal Processor (DSP)

Speed Range
0 - 3000 RPM

Frequency
50/60 Hz

Remote Control
Yes

Drive Type
Servo Drive

Application
Industrial Automation, Robotics, CNC Machines

IP Rating
IP65

Weight
Approx. 2.6 kg

Sensor Type
Encoder

Cable Length
Standard: 3 m

Material
Metal Body

Power
750 W

Temperature
-10°C to 40°C (Operating)

Voltage
200-240 V AC

Cooling Method
Natural Cooling

Max Instantaneous Peak Torque
2.45 Nm

Insulation Class
F

Encoder Resolution
20-bit

Max Allowable Axial Load
245 N

Max Allowable Radial Load
490 N

Frame Size
80 mm

Protection Class
IP65 (Shaft/IP67 possible with options)

Shaft Type
Straight

Life Expectancy
20,000 hrs (Rated)

Rotor Inertia
0.61 104 kgm2

Ambient Humidity
20% - 85% (No condensation)

Model Number
MHMD082S1V

About MHMD082S1V Panasonic Motor

MHMD 082 S1V

Series A5
Encoder ABC
Torque ( Nm ) 2.4
Rated RPM 3000
Installation
Commissioning
Programming
Wiring
Tracing
Design
Production trials
PRODUCTS : Controller , PLC , HMI , SCADA , Control Panel , Servo motor with Drive , AC motor with Drive , with DC Drive , with Drive
SYSTEM INTEGRATION PROJECTS
Other Similar Accessories and Upgraded Products MUMA5AZP1S, MUMA5AZP1T, MUMA012P1S, MUMA012P1T, MUMA022P1S, MUMA022P1T, MUMA042P1S, MUMA042P1T, MHMJ042P1U, MHMD042G1U, MHMJ082P1U, MHMD082G1U, MSME082G1V, MHMJ102P1G, MDME102GCGM, MDME152GCGM, MDME202GCGM, MDME302GCGM, MDME402GCGM, MDME502GCGM, MADHT1505, MADKT1505CA1, MBDJT2207, MADHT1507CA1, MADKT1507CA1, MBDJT2210, MBDHT2510, MBDKT2510CA1, MCDHT3520, MCDKT3520CA1, MCDJT3220, MCDJT3230, MDDHT3530, MDDKT3530CA1, MDDHT5540, MDDKT5540CA1, MEDHT7364, MEDKT7364CA1, MFDHTA390, MFDKTA390CA1, MFDHTB3A2, MFDKTB3A2CA1, MGDHTC3B4, MGDKTC3B4CA1, MHDHTC3B4, MHDKTC3B4CA1 and allied Connectors Cables.
Locations include Mumbai, Pune, Nagpur, Ahmedabad, Coimbatore, Bangalore, Rajkot etc

High Performance and Reliability

The MHMD082S1V Panasonic Motor boasts superior precision and reliability due to its built-in DSP and 20-bit encoder. Its strong build with IP65 protection and metal housing ensures steadfast performance in industrial automation environments. The natural cooling system and insulation class F safeguard the internal components, making this servo motor well-suited for continuous operation.

Versatile Application Range

Designed for use in industrial automation, robotics, and CNC machinery, the MHMD082S1V adapts seamlessly to varying tasks. Its flange mount and compact design allow for easy integration, while the fast response and stable operation make it essential for high-speed, high-precision processes.

Energy Efficiency and Long Lifespan

With its energy-efficient 750W output and effective natural cooling, the MHMD082S1V operates economically while offering a rated life expectancy of up to 20,000 hours. This durability reduces maintenance needs, translating to higher productivity and reduced operational costs over time.

FAQs of MHMD082S1V Panasonic Motor:

Q: How does the MHMD082S1V motor enhance precision and control in automation systems?

A: The MHMD082S1V features a 20-bit high-resolution encoder and a built-in digital signal processor (DSP), which ensures precise feedback and smooth control. This level of accuracy is essential for applications demanding meticulous positioning, such as robotics and CNC machinery.

Q: What types of environments are suitable for installing the MHMD082S1V Panasonic Motor?

A: This servo motor is suitable for industrial environments with ambient humidity between 20% and 85% (non-condensing) and operating temperatures from -10C to 40C. Its IP65 rating (with optional IP67 shaft protection) makes it resistant to dust and water, ideal for factories and automation lines.

Q: When is it recommended to use a straight shaft motor design, like in the MHMD082S1V?

A: A straight shaft is preferred when direct coupling to linear or rotary actuators is needed, offering minimal backlash and accurate torque transfer. This is particularly useful in precision automation and robotic applications where precise alignment is critical.

Q: Where can the MHMD082S1V be integrated within an industrial facility?

A: The MHMD082S1V is versatile and can be integrated into various automated systems, such as conveyor drives, robotic arms, and CNC machinery. Its flange mount design and compact form factor allow it to fit into restricted or complex equipment layouts.

Q: What is the process for maintaining the MHMD082S1V motor to ensure optimum performance?

A: Basic maintenance involves keeping the motor clean, ensuring proper ventilation for natural cooling, and periodically checking electrical connections. With its robust construction and insulation class F, the motor typically requires minimal servicing for its 20,000-hour rated lifespan.

Q: How does using the MHMD082S1V benefit industrial automation operations?

A: Utilizing this motor delivers increased efficiency due to its energy-saving design and dependable performance. Its high precision, long lifespan, and minimal maintenance contribute to reduced downtime and enhanced productivity in automated processes.
