Stepper Drive Leadshine

Get a Price/Quote

Product Details:

Connectivity Type USB and terminal connections
Components Drive circuitry connectors housing
Protection Class Ordinary
Rated Operation Voltage 24-48 VDC
Cover Material Metal
Control System Digital control
Cooling System Passive cooling
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Stepper Drive Leadshine Product Specifications

Application Stepper motor control
Features Microstepping high performance compact design
Way 2-phase step control
Warranty 1 year
Rated Operation Voltage 24-48 VDC
Surface Finish Smooth metal
Standard Industrial standard
Product Type Stepper Drive
Material Metal and plastic
Components Drive circuitry connectors housing
Protection Class Ordinary
Connectivity Type USB and terminal connections
Dimension (L*W*H) 105mm x 72mm x 33mm
Surface Color Grey
Rated Voltage 24-48 VDC
Operating Voltage 24-48 VDC
Cooling System Passive cooling
Base Material Metal
Cover Material Metal
Control System Digital control

Product Description

Stepper Drive Leadshine

Input Supply Voltage : : +48V DC

For Stepper motors upto 34 Kgcm ( 3.4 Nm Torque )

Integrated Package with Programming , Commissioning , Installation , Wiring , Documentation Circuit diagram

1) Motion Controller ( 4 Axis Interpolation )

2) PLC

3) Stepper motor

4) control panel

5) Total Solution under one roof

FAQs of Stepper Drive Leadshine:

Q: What is the warranty period for the Stepper Drive Leadshine?

A: The warranty period for the Stepper Drive Leadshine is 1 year.

Q: What is the control system used for the Stepper Drive Leadshine?

A: The control system used is digital control.

Q: What is the operating voltage range for the Stepper Drive Leadshine?

A: The operating voltage range is 24-48 VDC.

Q: What type of connectivity options are available for the Stepper Drive Leadshine?

A: The connectivity types available are USB and terminal connections.

Q: What is the surface color and finish of the Stepper Drive Leadshine?

A: The surface color is grey and the surface finish is smooth metal.
