Mycom Stepper PS 496-02A (B)

Get a Price/Quote

Product Details:

Components PS496-02A (B)
Base Material Metal
Features Compact dimensions
Product Type Stepper Motor
Material Metal
Dimension (L*W*H) 42mm x 42mm x 30mm (approx.)
Application Stepper Motor
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mycom Stepper PS 496-02A (B) Product Specifications

Components PS496-02A (B)
Application Stepper Motor
Base Material Metal
Product Type Stepper Motor
Features Compact dimensions
Dimension (L*W*H) 42mm x 42mm x 30mm (approx.)
Material Metal

Product Description

Mycom Stepper PS 496-02A (B)

Motor Model : PS 496-02A (B)

12.5 (kg-cm) Max.Holding Torque

560 (gcm2) Rotor Inertia

1.8º/0.9º (Step Angle) Half/Full

1.25 (Amps) Phase Current

5.5 (Vdc) Voltage

4.4 (Ohms) Phase Resistance

16 (mH 1KHz) Phase Inductance

1.45 (kg) Motor Weight

FAQs of Mycom Stepper PS 496-02A (B):

Q: What is the material of the Mycom Stepper PS 496-02A (B)?

A: The material used for the Mycom Stepper PS 496-02A (B) is metal.

Q: What is the application of the Mycom Stepper PS 496-02A (B)?

A: The Mycom Stepper PS 496-02A (B) is designed for use with stepper motors.

Q: What are the dimensions of the Mycom Stepper PS 496-02A (B)?

A: The dimensions of the Mycom Stepper PS 496-02A (B) are approximately 42mm x 42mm x 30mm.

Q: What are the features of the Mycom Stepper PS 496-02A (B)?

A: The Mycom Stepper PS 496-02A (B) is known for its compact dimensions.

Q: What components are included with the Mycom Stepper PS 496-02A (B)?

A: The Mycom Stepper PS 496-02A (B) includes the PS496-02A (B) components.
