46 Kgcm motor 34H-98-50-4A

Get a Price/Quote

Product Details:

Cover Material Aluminum
Control System Microcontroller-driven
Protection Level Basic enclosure protection
Cooling System Passive cooling
Current Rating 4A
Base Material Aluminum
Protection Class Class I
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

46 Kgcm motor 34H-98-50-4A Product Specifications

Cooling System Passive cooling
Protection Level Basic enclosure protection
Control System Microcontroller-driven
Cover Material Aluminum
Base Material Aluminum
Application Robotics and Industrial Automation
Rated Voltage 12V to 24V
Standard Industry standard motor specifications
Current Rating 4A
Operating Voltage 12V to 24V
Surface Finish Matte
Protection Class Class I
Features High torque precision control compact design
Way 4-wire bipolar configuration
IP Rating Ip40
Material Aluminum and steel
Connectivity Type Wired
Product Type Stepper motor
Maximum Output Current 4A
Rated Operation Voltage 24V
Dimension (L*W*H) 34mm x 98mm x 50mm
Warranty 1 year
Components Stepper motor wiring harness
Surface Color Silver and black
Rated Current 4A

Product Description

46 Kgcm motor 34H-98-50-4A

Bipolar Stepper motor46 Kgcm

NEMA34H

4 Lead / 8 Lead , Series / Parallel , Hybrid Stepper motors

Frame Size : : 28 mm to 110 mm

Capacity : : 10 Kgcm to 220 Kgcm

Current : : 1A to 6A

RPM : : Load Dependent Can go max upto 500 rpm

FAQs of 46 Kgcm motor 34H-98-50-4A:

Q: What is the maximum output current of the 46 Kgcm motor 34H-98-50-4A?

A: The maximum output current is 4A.

Q: What is the operating voltage range for the motor?

A: The operating voltage range is 12V to 24V.

Q: What is the warranty period for the motor?

A: The warranty period is 1 year.

Q: What is the application of the 46 Kgcm motor 34H-98-50-4A?

A: The motor is suitable for Robotics and Industrial Automation applications.

Q: What is the protection class of the motor?

A: The protection class is Class I.

Q: What is the connectivity type of the motor?

A: The connectivity type is wired.

Q: What is the surface color of the motor?

A: The surface color is silver and black.
