Soyo Stepping SY57STH41-3006A

Product Details:

Cover Material Aluminum
Rated Operation Voltage 12-24V DC
Features High precision step control
Operating Voltage 12-24V DC
Base Material Metal
Connectivity Type Wire or Connector
Rated Current 3.0A
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Soyo Stepping SY57STH41-3006A Product Specifications

Base Material Metal
Operating Voltage 12-24V DC
Control System Digital Pulse Control
Cooling System Passive cooling
Dimension (L*W*H) 57mm x 57mm x 41mm
Features High precision step control
Cover Material Aluminum
Rated Operation Voltage 12-24V DC
Maximum Output Current 3.0A
Standard ISO/CE certified
Rated Current 3.0A
Warranty 1 year
Product Type Stepper Motor
Connectivity Type Wire or Connector
Application Stepper Motor Control
Way 4-wire bipolar configuration
Components Rotor Stator Shaft
Rated Voltage 12-24V DC
Surface Color Silver and Black
Material Aluminum and Steel
Current Rating 3.0A
Surface Finish Brushed

Product Description

SY57STH41-3006A
1.9 (V) RatedVoltage
3 (A) Current/Phase
0.63 () Resistance/Phase
0.6 (mH) Inductance/Phase
3.9 (kg-cm) Holding Torque
6 ofLeads
120 (g-cm2) Rotor Inertia
0.45 (kg) Weight
0.21 (kg-cm) Detent Torque
41 (mm) Length

FAQs of Soyo Stepping SY57STH41-3006A:

Q: What is the warranty for Soyo Stepping SY57STH41-3006A?

A: The warranty for Soyo Stepping SY57STH41-3006A is 1 year.

Q: What is the rated current for Soyo Stepping SY57STH41-3006A?

A: The rated current for Soyo Stepping SY57STH41-3006A is 3.0A.

Q: What is the control system used in Soyo Stepping SY57STH41-3006A?

A: The control system used in Soyo Stepping SY57STH41-3006A is Digital Pulse Control.

Q: What is the material of the cover for Soyo Stepping SY57STH41-3006A?

A: The cover material for Soyo Stepping SY57STH41-3006A is Aluminum.

Q: What is the maximum output current for Soyo Stepping SY57STH41-3006A?

A: The maximum output current for Soyo Stepping SY57STH41-3006A is 3.0A.
