M752 Leadshine Stepper Drive

Get a Price/Quote

Product Details:

Control System Stepper Motion Control
Current Rating 6.0A
Rated Insulation Voltage None
Protection Level Over Voltage Over Current Protection
Rated Operation Voltage 20V-70V DC
Cooling System Passive Cooling
Base Material Aluminum
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

M752 Leadshine Stepper Drive Product Specifications

Application Industrial Automation
Cooling System Passive Cooling
Rated Operation Voltage 20V-70V DC
Dimension (L*W*H) 118 x 75.5 x 34 mm
Rated Voltage 20V-70V DC
Surface Color Black
Display Type None
Protection Level Over Voltage Over Current Protection
Rated Insulation Voltage None
Current Rating 6.0A
Warranty 1 Year
Product Type Stepper Drive
IP Rating IP20
Control System Stepper Motion Control
Surface Finish Matte Finish
Maximum Output Current 6.0A
Protection Class Class I
Panel Type None
Connectivity Type Wired
Standard CE certified
Rated Current 6.0A
Components Stepper Drive Module
Cover Material Plastic
Cabinet Material Metal
Thickness 3 mm
Way Bipolar 2-phase
Features High-speed performance Efficient motion algorithms Robust build quality
Frequency (MHz) None
Material Aluminum and Plastic
Operating Voltage 20V-70V DC
Base Material Aluminum

Product Description

Leadshine make Stepper Drive

Model M752 for Stepper motors upto 46 Kgcm

Features : :

1) High Performance , Cost Effective

2) Input Supply Voltage Upto +80V DC / 110V AC

3) Output Current : : Upto 7.8A

4) Pulse input Frequency Upto 300 Khz

5) TTL Compatible , Optically Isolated input

6) MicroStepping Type 1/256 steps resolution

7) Automatic Idle Current reduction

8) Suitable for 2 Phase / 4 Phase Stepper motors

9) Short Circuit , OverVoltage , OverCurrent , OverTemperature Protection

FAQs of M752 Leadshine Stepper Drive:

Q: What is the rated current of the M752 Leadshine Stepper Drive?

A: The rated current of the M752 Leadshine Stepper Drive is 6.0A.

Q: What is the IP rating of the M752 Leadshine Stepper Drive?

A: The IP rating of the M752 Leadshine Stepper Drive is IP20.

Q: What is the warranty period for the M752 Leadshine Stepper Drive?

A: The warranty period for the M752 Leadshine Stepper Drive is 1 Year.

Q: What type of cooling system does the M752 Leadshine Stepper Drive have?

A: The M752 Leadshine Stepper Drive has a passive cooling system.

**Q: What is the dimension of the M752 Leadshine Stepper Drive (LWH)?**

A: The dimension of the M752 Leadshine Stepper Drive is 118 x 75.5 x 34 mm.
