MYCOM Stepper motors

Get a Price/Quote

MYCOM Stepper motors Specification

Current Rating
1.2A/Phase

Rated Current
1.2A/Phase

Cover Material
Aluminium

Components
Rotor, Stator, Winding, Shaft

Connectivity Type
4 Wire

Rated Operation Voltage
12V DC

Control System
Microstep Drive Compatible

Features
High Torque, Low Noise, Precise Positioning

Protection Class
Class B

Operating Voltage
12V DC

Rated Insulation Voltage
250V AC

Thickness
45 mm (body length)

Protection Level
IP20

Product Type
Bipolar Stepper Motor

Surface Finish
Matte

Standard
IEC standard

Surface Color
Grey

Rated Voltage
12V DC

Maximum Output Current
1.2A/Phase

Dimension (L*W*H)
56 mm × 56 mm × 45 mm

Application
CNC Machines, Printers, Robotics, Automation Equipment

IP Rating
IP20

Holding Torque
1.65 Nm

Insulation Resistance
>100 M (500V DC)

Mounting
NEMA 23 Standard Mounting

Step Angle
1.8 per step

Dielectric Strength
500V AC for 1 minute

Shaft Diameter
6.35 mm

Weight
420 g

About MYCOM Stepper motors

Adhering to the industry standards and norms for qualitative production, we have successfully attained the name of reliable manufacturer and supplier of MYCOM Stepper Motors. These motors minimize pulsation and course vibration movements in industrial machinery. To manufacture the motor we use finest quality materials and components, sourced from the authentic vendors. The clients can obtain our MYCOM Stepper Motors in different sizes and specifications as per their requirements.

Features:

Low power consumption
Constant current chopper
High Torque

Mycom Make Stepper motors

Available from 10 Kgcm to 120 Kgcm ( 1 Nm to 22 Nm Torque )

Max Speed can go upto 500 rpm

Totally Integrated Solution Under one roof

1) Stepper motor

2) Stepper Drive

3) Power Supply

4) Motion Controller

5) Programmable Logic Controller with Display

6) Control PANEL Design with Site Wiring and Installation

Precision Engineering for Demanding Automation

MYCOM Stepper Motors offer high torque and fine positioning with a 1.8 step angle, perfect for CNC machines, printers, robotics, and automation equipment. Their NEMA 23 standard mounting ensures easy compatibility and replacement in industry setups.

Reliable Performance and Safety Compliance

With IEC-standard construction, IP20 protection, and Class B insulation, MYCOM ensures operational safety and longevity. The steppers robust dielectric strength and insulation resistance keep your systems reliably protected under rigorous operating conditions.

Versatile and User-Friendly Design

Weighing just 420 g with a 6.35 mm shaft diameter, this stepper motor features a 4-wire connectivity that supports microstep drives for advanced motion control. Its matte grey aluminium cover offers durability while facilitating heat dissipation during intensive operating cycles.

FAQs of MYCOM Stepper motors:

Q: How do I connect the MYCOM Stepper Motor to a control system?

A: The MYCOM Stepper Motor uses a four-wire configuration compatible with most microstep drives. Properly match the wiring to your stepper driver, following the provided schematic, and ensure that your control system is rated for 12V DC and up to 1.2A per phase.

Q: What applications are best suited for this stepper motor model?

A: This motor is ideal for CNC machines, printers, robotics, and automation equipment due to its high torque, precise 1.8 step angle, and durable construction. Its NEMA 23 standard mount makes it suitable for a range of industrial and automation setups.

Q: When should I choose this motor over other stepper motors?

A: Select this model when you require precise positioning, high holding torque (1.65 Nm), and compatibility with IEC standards. Its robust build and reliable performance at 12V DC make it a preferred choice for projects demanding accuracy and reliability.

Q: Where can I source or purchase the MYCOM Stepper Motor in India?

A: MYCOM Stepper Motors are available through authorized suppliers, service providers, manufacturers, and traders across India. Contact verified distributors or visit industrial automation retailers for procurement and support.

Q: What benefits does the MYCOM Stepper Motor offer compared to other motors?

A: It combines high torque output, low operational noise, and precise positioning with an insulation rating over 100 M and a rugged aluminium cover. The matte finish enhances thermal management, and the IP20 protection level ensures reliable operation in controlled environments.

Q: How does the motors thermal and electrical protection improve reliability?

A: With Class B insulation, a dielectric strength of 500V AC for 1 minute, and a rated insulation voltage of 250V AC, this stepper motor is engineered for safety, minimizing risks of electrical failure and supporting continuous industrial use.
