Stepper Drive YKC2608M Yako

Get a Price/Quote

Product Details:

Base Material Metal
Cabinet Material Aluminum
Rated Current 6A
Cover Material Aluminum
Cooling System Passive cooling
Features High performance multiple settings for motor control
Way Two-phase motor control
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Stepper Drive YKC2608M Yako Product Specifications

Maximum Output Current 6A
Operating Voltage 24-80VDC
Product Type Stepper Drive
Display Type LED indicators
Rated Voltage 24-80VDC
Panel Type Simple terminal panel
Warranty 1 Year
Control System Microcontroller-based stepper motor control
Connectivity Type Screw terminal connections
Components Stepper drive connectors
Standard CE
Material Aluminum body
Current Rating 6A
Rated Current 6A
Base Material Metal
Dimension (L*W*H) 148 x 105 x 50 mm
Cabinet Material Aluminum
Surface Color Silver
Surface Finish Polished
Features High performance multiple settings for motor control
Cover Material Aluminum
Application Stepper motor control
Cooling System Passive cooling
Way Two-phase motor control
Rated Operation Voltage 24-80VDC
Protection Level Overcurrent protection

Product Description

YAKO Stepper Package

Model

YKC2608M

High Performance , Low Price

32 kinds of Microstep Selection

Once Pulse Stops for 100ms ,the Phase current will automatically reduce to Preset Value

Bipolar Constant Current Chopper Control

Step Angle Accuracy : 5%

Temperature 80 degree Celsius max

Insulation Resistance : 100 Mohm at 500V DC

Voltage Endurance : 500V AC 1 minute

Shaft Radial Play : Max 0.06 mm (450g )

Shaft Axial Play : Max 0.08 mm ( 450g )

FAQs of Stepper Drive YKC2608M Yako:

Q: What is the maximum output current rating of Stepper Drive YKC2608M Yako?

A: The maximum output current rating of Stepper Drive YKC2608M Yako is 6A.

Q: What is the operating voltage range for Stepper Drive YKC2608M Yako?

A: The operating voltage range for Stepper Drive YKC2608M Yako is 24-80VDC.

Q: What type of control system does Stepper Drive YKC2608M Yako have?

A: Stepper Drive YKC2608M Yako has a microcontroller-based stepper motor control system.

Q: What is the warranty period for Stepper Drive YKC2608M Yako?

A: Stepper Drive YKC2608M Yako comes with a 1-year warranty.

Q: What type of cooling system does Stepper Drive YKC2608M Yako have?

A: Stepper Drive YKC2608M Yako has a passive cooling system.
