Delta PLC DVP20ES2

Get a Price/Quote

Delta PLC DVP20ES2 Specification

Frequency
50/60 Hz

Remote Control
Yes

Cable Length
Not Included

Application
Industrial automation, machinery control

IP Rating
IP20

Phase
Single Phase

Weight
Approximately 400g

Control Type
PLC (Programmable Logic Controller)

Automation Grade
Automatic

Mounting Type
DIN Rail Mounting

Material
Plastic and Metal

Power
24V DC, 5W

Temperature
0°C to 55°C (Operating)

Input Voltage Range
24V DC (Inputs)

Program Capacity
8k Steps

Programming Software
WPLSoft

Input Points
12 (Digital Input)

Dimensions
90 mm x 90 mm x 55 mm

Expansion Capability
Supports I/O extension modules

Pulse Output Frequency
10kHz (max)

Output Points
8 (Relay Output)

Data Register
5k Words

Output Type
Relay

About Delta PLC DVP20ES2

Delta PLC DVP20ES2

MPU points: 16 / 20 / 24 / 32 / 40 / 60
Program capacity: 16k steps
Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to operate independently (Master/Slave)
Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points
DVP-EX2 MPU is built in with 12-bit 4AD/2DA and offers analog/temperature modules of 14-bit resolution.
Built-in with 8 high-speed input points (2 points for 100kHz, 6 points for 10kHz) and supports U/D, U/D Dir, A/B counting modes
New motion control instructions: Close loop control, alignment mark, shield, immediate variable speed, S-Curve acceleration/deceleration
Application in emerging industry: Exclusive instructions and function blocks designed for PV solar tracker
Handy instructions for frequency inverter: For controlling the forward running, reverse running, RUN and STOP of Deltas AC motor drives
Password protection: Password for subroutine, user ID, restriction on trial times
Highly efficient instruction efficient instruction execution

Versatile Industrial Automation Control

Deltas DVP20ES2 PLC offers flexibility for complex automation tasks in industries ranging from manufacturing to process control. Its combination of 12 digital inputs and 8 relay outputs enables sophisticated operations, adaptable for broader systems through I/O expansion modules. The compact size makes installation practical in space-constrained panels.

Expanded Programming and Data Management

With a program capacity of up to 8k steps and 5k data registers, the DVP20ES2 ensures efficient management of process variables, scheduling, and logic sequences. WPLSoft programming software provides an intuitive interface, enabling engineers and technicians to configure and manage the PLC with ease.

FAQs of Delta PLC DVP20ES2:

Q: How can the Delta DVP20ES2 PLC be expanded for larger projects?

A: The DVP20ES2 supports I/O extension modules, allowing users to add additional input and output points as project needs grow. Expansion modules are connected via designated ports, making it simple to enhance the system for more complex automation requirements.

Q: What is the typical usage of the DVP20ES2 in industrial settings?

A: This PLC is widely used for machinery control and automated process management in industrial environments. Its relay outputs and digital inputs make it suitable for controlling conveyors, pumps, and other industrial equipment within manufacturing plants or processing facilities.

Q: When is it best to use relay output type PLCs like the DVP20ES2?

A: Relay output PLCs are ideal when controlling a variety of loads, including AC and DC devices. The DVP20ES2s relay outputs provide electrical isolation, making it suitable in applications where different voltage levels must be switched or safety is prioritized.

Q: Where should the DVP20ES2 be installed for optimal operation?

A: Install the PLC in a control cabinet using DIN rail mounting for secure placement. Ensure the setting is within the operating temperature range (0C to 55C) and protected from dust or moisture, as indicated by its IP20 rating.

Q: What benefits does programming with WPLSoft provide for the DVP20ES2?

A: WPLSoft offers a user-friendly programming environment, enabling efficient ladder logic development, simulation, and troubleshooting. It simplifies project setup and reduces commissioning time, streamlining the automation process.

Q: How much power does the Delta DVP20ES2 consume during operation?

A: The PLC operates on 24V DC and consumes approximately 5W, making it energy-efficient for continuous industrial use.

Q: What is the process for integrating the DVP20ES2 into an existing automation system?

A: Integration involves mounting the PLC on a DIN rail, wiring the input and output terminals to field devices, and setting up the program in WPLSoft. The system can be tested and adjusted before going fully operational to ensure smooth integration and control.
