Messung XMP8-11 BDIO 16/12R

Get a Price/Quote

Messung XMP8-11 BDIO 16/12R Specification

Frequency
50-60 Hz

Mounting Type
DIN Rail Mounting

Features
LED Status Indication, High Density I/O, Compact Design

Weight
Approx. 180 grams

Automation Grade
Automatic

Application
PLC Input/Output Expansion in Automation Systems

Load Capacity
Supports up to 16 DI/12 DO

Processor Type
Compatible with Messung XMP8-11 Series PLC

IP Rating
IP20

Phase
Single Phase

Remote Control
Yes

Control Type
Digital IO (Input/Output)

Connectivity Type
Screw Terminal Connections

Material
Industrial Grade Components

Power
24 V DC

Temperature
0C to 50C Operating

Voltage
24 V DC (Input Voltage)

No. of Relay Outputs
12 (Relay Outputs 2A@30VDC)

Output Response Time
< 10 ms

Dimensions
140 mm x 92 mm x 58 mm

Output Signal Type
Relay

Input Response Time
< 5 ms

Insulation Voltage
500V AC RMS for 1 min

Input Signal Type
Digital

No. of Digital Inputs
16 (24 V DC Sink/Source)

Product Type
BDIO 16/12R Expansion Module

Compatible PLC Series
Messung XMP8 Series

Humidity
5% to 95% RH (Non-condensing)

About Messung XMP8-11 BDIO 16/12R

MESSUNG XMP8 MICRO Series 16/12R

Number of Inputs/Outputs : 28

Input Power Supply : 24V DC

Outputs Type : Relay

Compact Design

MMI Connectivity

Doxmini Software - Powerful Programming and Documentation based Software

PG308 - Compact Portable Handheld Programming Terminal

Expansion Modules - Discrete and Analog

High-Density Digital I/O Expansion

The BDIO 16/12R module offers a combination of 16 digital inputs and 12 relay outputs, providing flexible and scalable I/O expansion for industrial automation setups. Its compact footprint allows high-density installation, making it suitable for systems requiring numerous control and monitoring points.

Reliable Performance in Industrial Environments

Engineered with industrial-grade materials, this module operates effectively across a broad temperature range (0C to 50C) and in high humidity (5%95% RH, non-condensing). With insulation of 500V AC RMS and an IP20 rating, it ensures durability and operational safety in challenging conditions.

Quick Response and Simple Installation

Designed for fast operation, inputs respond in under 5 ms and outputs engage in less than 10 ms. The module features screw terminal connections for secure wiring and DIN rail mounting, streamlining assembly and maintenance for automation engineers.

FAQs of Messung XMP8-11 BDIO 16/12R:

Q: How can the BDIO 16/12R module be used within an automation system?

A: The BDIO 16/12R module expands digital input and relay output capacity when connected to a Messung XMP8 Series PLC. It is ideally suited for environments requiring control and monitoring of numerous field devices, such as sensors and actuators, within industrial automation systems.

Q: What is the process for installing this expansion module?

A: To install the BDIO 16/12R, securely mount it on a DIN rail, wire the digital inputs and relay outputs via the screw terminal connections, and connect the communication cables to the XMP8 Series PLC. Ensure proper power supply (24 V DC) and observe safety measures during the installation process.

Q: When should I choose this module for my application?

A: Select this module when your automation setup needs more digital inputs and relay outputs than your base XMP8 Series PLC offers. It is especially suitable when high density, reliability, and fast signal response are priorities in your control system.

Q: Where can I use the Messung XMP8-11 BDIO 16/12R expansion module?

A: The module is designed for industrial automation environments across sectors such as manufacturing, process control, and utility management in India. Its robust construction and wide operating range make it suitable for demanding applications.

Q: What benefits does the LED status indication provide?

A: LED status indication simplifies system diagnostics by clearly displaying the operational state of each input and output channel. This helps reduce troubleshooting time and ensures the module is functioning correctly.

Q: How does the module ensure safe operation?

A: Safety is achieved through features like 500V AC RMS insulation voltage and a robust IP20 enclosure, protecting users and equipment from electrical hazards and dust ingress during use.
