DM422 Stepper Drive 2.2A Leadshine

Get a Price/Quote

Product Details:

Base Material Metal
Way Bipolar drive
Features High voltage low voltage signal indicators
Control System Microstepping control
Rated Operation Voltage 18-40V DC
Cover Material Plastic
Connectivity Type Wired connection
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DM422 Stepper Drive 2.2A Leadshine Product Specifications

Current Rating 2.2A maximum output current
Display Type None
Cooling System Passive cooling
Rated Current 2.2A
Cabinet Material Plastic
Rated Voltage 18-40V DC
Operating Voltage 18-40V DC
Components Stepper drive controller
Dimension (L*W*H) 85mm x 65mm x 25mm
Product Type Stepper drive
Surface Finish Matte
Base Material Metal
Maximum Output Current 2.2A
Standard Leadshine standard
Surface Color Black
Rated Operation Voltage 18-40V DC
Material Metal and plastic
Control System Microstepping control
Features High voltage low voltage signal indicators
Warranty 1 year
Way Bipolar drive
Cover Material Plastic
Connectivity Type Wired connection
Application Stepper motor control

Product Description

DM422 Stepper Drive 2.2A

Digital Stepper Drive ( Upto 20 Kgcm Stepper motors )

Supply Voltage : Upto 40V DC

Supports PUL/DIR and CW/CCW modes

Current : 0.3A to 2.2A Settable

Automatic Idle Current reduction

Allied Accessories : Pulse generators , Stepper motors , PLC , Motion Controllers

FAQs of DM422 Stepper Drive 2.2A Leadshine:

Q: What is the rated voltage for the DM422 Stepper Drive 2.2A Leadshine?

A: The rated voltage for the DM422 Stepper Drive 2.2A Leadshine is 18-40V DC.

Q: What is the maximum output current for the DM422 Stepper Drive 2.2A Leadshine?

A: The maximum output current for the DM422 Stepper Drive 2.2A Leadshine is 2.2A.

Q: What type of control system does the DM422 Stepper Drive 2.2A Leadshine have?

A: The DM422 Stepper Drive 2.2A Leadshine has a microstepping control system.

Q: What is the warranty period for the DM422 Stepper Drive 2.2A Leadshine?

A: The DM422 Stepper Drive 2.2A Leadshine comes with a 1 year warranty.

Q: What is the application of the DM422 Stepper Drive 2.2A Leadshine?

A: The DM422 Stepper Drive 2.2A Leadshine is used for stepper motor control.
